Polyurethane Decorative Wall Panel Moulding P85003
Technical Specifications
| Material | Polyurethane |
|---|---|
| Surface | Smooth, flat |
| Color | White |
| Density | 150-220 kg/m³ |
| Water Absorption | below 1% |
| Dimensional Stability Test | -20 °C / +70 °C |
| Fire Class | B2 (DIN 4102-1) |
| Paintable | Yes |
| Usage | Indoor + Outdoor |
| Water Resistant | Yes |
| Dimensions | 12 × 2400 × 16 mm |
| Weight | 0.18 kg |
| Sales Unit | piece |
Details
Support
Technical drawing: Download DWG (195 KB)
Similar Products(Wall Panel Trim Moldings)
















The polyurethane P85003 decorative moulding is a premium architectural trim designed to bring clean lines and structured elegance to modern interior and exterior spaces. With its compact dimensions of 12 mm in depth, 16 mm in height, and a generous length of 2400 mm, this slim-profile moulding is exceptionally versatile. It acts as a precise design tool for architects and interior designers looking to create custom wall paneling, geometric boiserie frames, or subtle transitions between different surface materials without overwhelming the room's overall aesthetic.
Engineered from high-density rigid polyurethane with a density of 150-220 kg/m³, this product offers a surface hardness comparable to premium timber while remaining remarkably lightweight. Its closed-cell internal structure provides low water absorption (below 1%), making it moisture-resistant and helping limit rot and insect damage. Unlike traditional wood or MDF mouldings, the P85003 will not warp, shrink, swell, or crack over time, guaranteeing a stable installation that maintains its flawless dimensions indefinitely.
A close inspection of the profile reveals a sophisticated asymmetrical design, featuring a flat face that steps down into a delicate, rounded bead on one side. This specific geometry creates sharp, defined shadow lines when installed on walls or ceilings, adding a three-dimensional depth to flat surfaces. The minimalist and clean nature of this profile makes it highly suitable for contemporary, Scandinavian, or transitional design schemes, offering a refined European aesthetic that enhances the architectural value of any project.
The application possibilities for this slim trim are extensive. In residential interiors, it is ideal for creating double-frame wall panels in living rooms, dining areas, and bedrooms, or as a delicate border around doors and windows. In commercial venues such as hotels, boutiques, and offices, its high impact resistance makes it perfect for high-traffic areas. Additionally, because of its superior weather resistance, it can be applied to exterior facades to create elegant paneling, window borders, and horizontal division lines.
Installation is straightforward and efficient. The moulding is easily cut with standard woodworking tools to achieve precise 45-degree miter joints. It is mounted using a high-quality polyurethane (PU) assembly adhesive, supplemented with mechanical fasteners such as small screws or brad nails to ensure long-term stability. The product comes pre-finished with a high-quality factory primer. While this primer prepares the surface for final painting, the application of an additional primer coat is optional and remains at the sole discretion of the installer, depending on the paint brand used.
Investing in the polyurethane P85003 means choosing a long-lasting, low-maintenance architectural detail. It bridges the gap between traditional craftsmanship and modern material science, offering a shatterproof, moisture-resistant, and easily paintable alternative to gypsum plaster and wood. This trim provides professional-grade durability and an impeccable finish that elevates the visual standards of any building project.
- The polyurethane P85003 moulding is a highly adaptable trim ideal for a wide range of decorative and functional applications
- In residential spaces, it is primarily used to create classic and modern wall paneling (boiserie) in living rooms, hallways, dining areas, and master bedrooms, giving plain walls an elegant, structured appearance
- It works beautifully as a delicate border to frame wallpaper inserts, artwork, or mirrors
- In commercial environments like boutique hotels, restaurants, and executive offices, it provides impact-resistant detailing along corridors and lobbies
- Assess water and moisture exposure using the product technical data, surface finish and installation details
- When coated with a UV-resistant exterior paint, this profile is excellent for outdoor applications, including window and door surrounds, facade paneling, and decorative trim under roof eaves on villa exteriors
- To achieve a professional installation of the polyurethane P85003 moulding, ensure the mounting surface is clean, dry, and flat
- Cut the profiles to the desired lengths and angles using a fine-toothed hand saw or a compound miter saw
- Apply a continuous bead of high-quality polyurethane (PU) assembly adhesive along the rear bonding channels of the moulding; do not use standard silicone
- Press the moulding firmly against the wall and secure it mechanically with brad nails or screws to prevent movement while the adhesive cures
- Fill all joints, miter cuts, and nail holes with an appropriate acrylic filler or joint compound
- Once the filler is completely dry, sand the surface smooth using 180-220 grit sandpaper
- The moulding is supplied with a factory-applied primer
- The decision to apply an additional primer coat before the final paint is optional and should be made based on the specific paint manufacturer's recommendations
- Finish by applying two coats of water-based or synthetic paint
- For exterior installations, the use of a high-quality UV-resistant paint is mandatory
- Maintaining the pristine look of the Polyurethane P85003 moulding requires minimal effort
- Its closed-cell, non-porous surface does not absorb dust or grime, allowing it to be cleaned easily with a damp cloth or a soft sponge dipped in warm, soapy water
- Avoid using highly abrasive cleaning pads, steel wool, or strong chemical solvents, as these can scratch or degrade the paint finish
- For outdoor installations, we recommend a simple visual inspection of the paint layer every few years to ensure the UV-protective coating remains intact and to repaint if any weathering is observed
Can the polyurethane P85003 moulding be installed in bathrooms or wetrooms?
Yes, absolutely. Because it is manufactured from high-density rigid polyurethane, it features a closed-cell structure with a water absorption rate under 1%. Assess water and moisture exposure using the product technical data, surface finish and installation details.
What type of adhesive should I use for installing this polyurethane trim?
We strictly recommend using a dedicated polyurethane (PU) assembly adhesive for bonding the moulding to the wall or ceiling. Standard silicone adhesives do not provide the necessary chemical bond for polyurethane and should be avoided. For the best results, supplement the adhesive with mechanical fasteners like screws or nails.
Does the P85003 moulding require an additional primer before painting?
The P85003 comes pre-treated with a high-quality factory-applied primer that is ready for painting. However, paint manufacturers often require their own specific primers to honor their paint performance warranties. Therefore, applying an extra layer of primer is optional and left to the installer's preference.
Is this profile durable enough to withstand impacts in busy corridors?
Yes. With a density of 150-220 kg/m³, this rigid polyurethane moulding has a surface hardness similar to wood. It is highly impact-resistant, shatterproof, and durable, making it an excellent choice for low-level wall framing in high-traffic commercial and residential hallways.
Can I use this moulding on the exterior of my house?
Yes, the P85003 is fully suitable for outdoor use due to its excellent dimensional stability and weather resistance. However, because polyurethane can yellow when exposed to direct sunlight over time, it is mandatory to paint the moulding with a high-quality, UV-resistant exterior paint to protect it from UV degradation.
